• Pipe Size: 25 mm (1 in)
• Maximum Working Pressure: 232 PSI (16 BAR)
• Vacuum Level: 29.84 in Hg / -0.98 BAR
• Working Temperature: -20 to 80 °C

Material(s):
• 100 % Aluminum, EN AB 46100
• Gripping Teeth: Stainless steel
• Seal: NBR with teflon coated treatment

Features and benefits

• Using the innovative one assembly connection technology, the TOPRING PPS fittings are entirely made of Aluminum

2-piece FITTING
• Aluminum body and nut

LEAKPROOF CONNECTION:
• Lubricated teflon coated blue seal
• Perfectly leaktight even under the hardest conditions

HIGH-PERFORMANCE INTERNAL GRIP DESIGN
• Stainless steel ring with gripping teeth for increased grip, strength and safety
• Internal components are securely maintained inside the fitting
• It is a great advantage, especially during installation, because it prevents the components to fall in pieces and it eliminates reassembly errors

Operation and installation

INSTALLATION TIP
View TOPRING PPS compressed air piping system video at TOPRING.com / Ressource Center for useful informations and installation tips

Caution

• Installation of TOPRING PPS compressed air piping system must be made according to the assembly instructions as indicated in the installation guide
• Carefully read the technical manual and the installation guide prior to proceeding

Applications

• Compressed air
• Vacuum
• Inert gases
