Product Features:
• Adjustable upper/lower ball bearing blade guide system
• Rack and pinion height adjustment system
• 2 speeds
• 2 x 4” dust chutes for dust collector hook-up
• Quick release blade change lever
• Cutting height indicator
• Blade tension meter and tracking can be seen through conveniently placed
windows
• 10° left / 45° right square cast iron tilting table
• Hinged doors for quick access to the blade
• Motor, blade, miter gauge and precision “TRU-RIP” aluminum rip fence with
resaw guide included
KC-2102FXB
20-1/4″
21″ x 21″
37-1/2″
152-1/8″ x (1/8″ – 1-1/4″) x 0.025″
12″
16 Amp. / 8 Amp.
110V / 220V, 1 Phase, 60 Hz
220V
2 (1,890-3,800) SFPM
40″ x 31″ x 80″ / 460 lbs
MODEL
CUTTING CAPACITY FRAME TO BLADE
TABLE SIZE
TABLE HEIGHT FROM FLOOR
BLADE SIZE
HEIGHT OF CUT
MOTOR
VOLTAGE
PRE-WIRED AT
SPEED
ASSEMBLED DIMENSIONS (LxWxH) / WEIGHT
36-1/4″ x 20-7/8″ x 85-7/8″ / 480 lbs
7 72995 00211 5
PACKAGING DIMENSIONS (LxWxH) / WEIGHT
